Overview
Wi-Fi Single-Live-Wire Smart Switch Solution
With the rapid adoption of smart homes, the intelligent upgrade of traditional switches faces challenges such as complex wiring, high installation costs, and high power consumption. Most households are wired with only a single live wire, while most smart switches on the market require both live and neutral wires, making retrofits difficult. Fanlun Technology has launched a Wi-Fi single-live-wire smart switch solution based on its low-power Wi-Fi SoC chip series, designed specifically to address these pain points. The solution fully leverages the low-power characteristics and excellent RF performance of this chip series, controlling current at 600–800 µA while maintaining Wi-Fi connectivity, thereby avoiding abnormalities such as lamp flickering. It supports the latest Wi-Fi 6 protocol, the Matter smart home standard, and multiple cloud platforms, allowing users to enjoy a smart life without rewiring and providing an efficient and economical path for the intelligent upgrade of traditional homes.
Applications
Industry Challenges
Wiring Limitations
About 90% of existing homes are wired with only a live line, while traditional smart switches require a neutral wire and raise retrofit cost significantly.
Lamp Compatibility Issues
Many single-live switches on the market cause LED flicker or faint glowing when connected to lighting fixtures.
Excessive Power Consumption
Maintaining Wi-Fi connectivity often produces high standby current, causing abnormal lamp behavior or shortening battery life in related devices.
Insufficient Signal Coverage
Ordinary smart switches often have weak wall-penetration capability, creating dead zones in large homes and multi-floor spaces.
Security Risks
IoT devices are vulnerable to attacks, and weak firmware security can expose user data.
Fragmented Ecosystems
Different brands often cannot interoperate, locking users into isolated ecosystems.
Complex Installation
Many products require professional electricians, making self-installation difficult and slowing market adoption.
Our Solution
Wi-Fi Single-Live-Wire Smart Switch Solution
Fanlun's Wi-Fi single-live-wire smart switch solution is based on its low-power Wi-Fi SoC chip series and effectively solves multiple challenges of smart switches in single-live-wire scenarios through hardware-software co-optimization. The solution adopts dynamic power management technology, which can intelligently adjust CPU frequency and RF power according to application requirements. While maintaining a stable Wi-Fi connection, it controls the operating current at 600–800 µA, thoroughly resolving the LED lamp flickering issue. This chip series features excellent RF performance (RX sensitivity -98.4 dBm, TX power 21 dBm), ensuring stable connectivity in complex home environments and maintaining an effective communication distance of 20 meters even through three walls. In terms of security, the solution integrates RSA-3072-based secure boot and AES-128-XTS Flash encryption to prevent unauthorized firmware execution and data leakage. The solution supports the Matter standard for cross-ecosystem device interoperability; it is compatible with a supporting cloud platform and mainstream public clouds, providing remote control, OTA upgrades, and device sharing. The hardware design adopts a modular architecture and is compatible with standard 86-type switch panels, making installation simple enough for ordinary users to complete the replacement in 10 minutes. The entire solution provides full-stack support from chips and modules to complete reference designs, greatly reducing customer development barriers and costs.
Core Capabilities
01Outstanding Hardware Performance
Industry-Leading RF Capability: Wi-Fi RX sensitivity reaches -98.4 dBm, with TX power up to 21 dBm.
Ultra-Long Communication Range: Up to 500 meters in open environments, and maintains a stable 20-meter connection through three walls.
Extreme Low Power Consumption: Current is only 600–800 µA in Wi-Fi connected state, completely resolving LED lamp flickering.
Wi-Fi 6 Support: Chip platforms supporting the latest Wi-Fi 6 protocol, providing higher efficiency and lower latency.
Bluetooth Coexistence: Also supports Bluetooth 5 (LE), providing short-range configuration and control capabilities.
02Enterprise-Class Security
Hardware-level encryption with RSA-3072 secure boot to ensure only authorized firmware runs and AES-128-XTS protection for flash contents.
Secure communication backed by a built-in hardware encryption accelerator and support for multiple encryption standards.
Secure OTA with end-to-end encrypted firmware delivery to prevent man-in-the-middle attacks and tampering.
03Seamless Ecosystem Compatibility
Matter support for cross-platform interoperability that breaks ecosystem silos.
Multi-cloud access with native ESP RainMaker support plus compatibility with major platforms such as AWS IoT and Alibaba Cloud.
Local control over Bluetooth or LAN even when the Internet is unavailable, preserving service continuity.
04Comprehensive Development Support
Complete Reference Design: Provides hardware design compatible with standard 86-type panels and a single-live-wire power supply solution.
Optimized Software Suite: Provides complete development environment support, including power optimization guides and sample code.
Mass Production Services: Provides pre-configured secure modules and certification support, simplifying the entire process from development to mass production.
Application Ecosystem: Provides iOS/Android reference app frameworks to shorten UI development cycles.
Customer Value
Lower Installation Cost
No rewiring is needed, installation cost drops by about 70%, and end users can often install the switch themselves.
Product Differentiation
Outstanding Wi-Fi performance and wall-penetration capability significantly improve user experience and product reputation.
Shorter Development Cycles
Complete reference designs and technical support can cut time to market by 50%.
Stronger Market Competitiveness
Matter support breaks ecosystem barriers and expands the reachable user base.
Optimized Maintenance Cost
Stable firmware and remote diagnostics can reduce after-sales issues by 40%.
Security and Compliance Assurance
Built-in advanced encryption supports compliance with data-security requirements such as GDPR.
Expanded Revenue Models
Cloud-based value-added services create recurring business opportunities.
Lower Energy Consumption
Intelligent lighting control can reduce electricity consumption by more than 30%, aligning with green development goals.
Higher Brand Value
High-performance, high-reliability products reinforce a professional brand image and increase user loyalty.
